Series 2000 Combination Boiler

Series 2000 Combination Boiler

The Series 2000 for combination applications are ready-to-install packaged systems that provide Domestic Hot Water and Space Heating from one vessel.

Series 2000 Combination Boiler can burn:
Natural Gas, Propane, #2 Oil, Dual Fuel

Not what you’re looking for? Check out our other boiler rental options.

Key Features

Burner and Boiler are a UL listed package.
UL Listed Gas Trains and Control Systems.
Choice of Power Burners.
Main and Auxiliary Gas Valves
Air Flow Switch
Flame Safeguard
Manual Main, Leak Test, and Pilot Gas Shutoff Valves
Bell and Gossett Circulating Pumps
Honeywell Aquastat Relay
Automatic Low Water Cutoff
Honeywell Second High-Limit With Manual Reset.
Burner Control Relay.
High Visibility Operating Light.
Pressure/Temperature Gauge
Pressure Relief Valve
2″ Diameter Firetubes of SA178-A Steel
Turbulators for Maximum Heat Transfer
Rail Legs
Lifting Lugs
2 Inches of Insulation With a Painted Steel Jacket.

Burner and Boiler are a UL listed package.
UL Listed Gas Trains and Control Systems.
Choice of Power Burners.
Main and Auxiliary Gas Valves
Air Flow Switch
Flame Safeguard
Manual Main, Leak Test, and Pilot Gas Shutoff Valves
Bell and Gossett Circulating Pumps
Honeywell Aquastat Relay
Automatic Low Water Cutoff
Honeywell Second High-Limit With Manual Reset.
Burner Control Relay.
High Visibility Operating Light.
Pressure/Temperature Gauge
Pressure Relief Valve
2″ Diameter Firetubes of SA178-A Steel
Turbulators for Maximum Heat Transfer
Rail Legs
Lifting Lugs
2 Inches of Insulation With a Painted Steel Jacket.

All necessary hot water boiler controls and secondary plumbing are in place and pre wired, and the vessels easily fit through a three foot wide doorway, resulting in a very quick start-up. Firing rate goes up to 2100MBTU, and many millions of BTU’s can be delivered by creating an efficient, fully modular system of many vessels operated by our control panel.

Standard features include nationally known parts and controls that are quickly available at most supply houses, allowing for easy quick and easy repair and maintenance, which can dramatically reduce down time.

Superior Boiler offers many options:

Choice of burner manufacturers fired by natural gas, oil, propane, or combination fuel.
Spark Ignition System for Combination Fuel Burners
Low-High-Low and Modulating gas trains
CSD-1, IRI, FM
Low-High-Low and Modulating Gas Trains with Motorized Valves
Fan-Damper relays
Louver Box for Sealed Combustion Side-Wall Venting
Barometric Dampers and Galvanized Tees
Extra Clean-out Openings and Plugs
Microprocessor Control Panel
Factory built Primary Mains and Headers
Immersion Aquastats
Various Relief Valve sizes for different applications

The Series 2000 is manufactured to exceed ASME Section IV standards and typically is used to provide supply temperatures from the coil of between 140-180°F, yet can accept extremely low return temperatures (below 100°F) without shocking the boiler. The Space Heating side of this boiler can provide supply temperature up to 200°F, and return temperature can go as low as 140°F. The temperature of the coil water is impacted by the temperature of the Space Heating side because the coil is immersed in that water. These vessels feature 70 vertical firetubes, each of which is 2″ diameter, 12 gauge steel and fitted with a high-efficiency turbulator for maximum heat transfer. The combustion chamber is fully water-backed, with burners that are UL listed.

A well-made, rugged vessel is naturally a safer. Superior Combination Boilers also have a firebox design that is completely backed by water, along with safety controls that results in a very safe and secure package.
