Series 1600 Steam Low Pressure Boiler

Series 1600 Steam Low Pressure Boiler

The Series 1600 Steam Boiler is available with firing inputs from 1100MBTU to 1700MBTU. However, millions of BTU’s can be delivered by creating an efficient, fully modular system sequenced by a control panel.

Series 1600 Steam Low Pressure Boiler can burn:
Natural Gas, Propane, #2 Oil, Dual Fuel

Not what you’re looking for? Check out our other boiler rental options.

Key Features

UL Listed Gas Trains and Control Systems.
Power Burners.
0-30 lb Pressure Gauge
15 lb Pressure Relief Valve
P7810C Solid State Pressure Control, Manual Reset
150 Water Level Control
Manual Reset Low Water Cutoff
Gauge Glass Assembly
Honeywell Aquastat Relay
Burner Control Relay
2″ Diameter Firetubes of SA178-A Steel
Turbulators for Maximum Heat Transfer
One Inch of high performance Insulation With a Painted Steel Jacket.

UL Listed Gas Trains and Control Systems.
Power Burners.
0-30 lb Pressure Gauge
15 lb Pressure Relief Valve
P7810C Solid State Pressure Control, Manual Reset
150 Water Level Control
Manual Reset Low Water Cutoff
Gauge Glass Assembly
Honeywell Aquastat Relay
Burner Control Relay
2″ Diameter Firetubes of SA178-A Steel
Turbulators for Maximum Heat Transfer
One Inch of high performance Insulation With a Painted Steel Jacket.

Standard features include nationally known parts and controls that are quickly available at most supply houses, allowing for quick and easy repair and maintenance, which can dramatically reduce down time.

Superior Boiler offers many options:

Choice of burners fired by natural gas, oil, propane, or dual fuel.
Low-High-Low or Modulating gas trains.
Fan-Damper relays
Clean-out openings and plugs

The Series 1600 Steam Boiler is manufactured to exceed ASME Section IV standards and is capable of providing operating pressure of up to 15 psi with nominal operating temperature of 218°F to 240°F. These vessels contain 70 vertical firetubes, each of which is 2″ diameter, 12 gauge steel, each fitted with a high-efficiency turbulator for maximum heat transfer. The combustion chamber is fully water-backed, with burners that are UL listed.

A well-made, rugged vessel is naturally a safer boiler. But Superior Boilers also have a firebox design that is completely backed by water, along with safety controls on the boiler that results in a very safe and secure package.

Series 1600 Steam Low Pressure Boiler
